Welcome to Beacon Huntress

Beacon Huntress

Beacon Huntress uses a combination of Python and Machine Learning to identify potential beacons.

Fast/Slow Beacon

Throughout this documentation you will see the terms Fast Beacon and Slow Beacon. These terms describe two different beaconing patterns based upon the time interval that passes between connection events.

  • A Fast Beacon is a beacon that has a short interval time. We consider anything <= 5 minutes to be a Fast Beacon.
  • A Slow Beacon is a beacon that has a long interval time. We consider anything > 5 minutes to be a Slow Beacon.
Note

Beacon Huntress was tested using HTTP/HTTPS beacons. This version of Beacon Huntress has not yet been tested using DNS beacons -- although it should work.

How to use Beacon Huntress

Beacon Huntress can be used in two ways: via Docker or a Jupyter Notebook.

Warning

For the purposes of this documentation, Beacon Huntress is assumed to have been downloaded via Git.

To run Beacon Huntress, you will need to answer the following questions:

  1. Where are my Zeek logs located?
  2. Do I want to filter out any connections in my logs?
  3. How many minutes do potential beacons wait before calling back? Are the beacons Fast or Slow?
  4. How many connections does a potential beacon need to have in order to be reported?

With answers to these questions, you can begin to configure Beacon Huntress to run. Check the Tutorial section for an example.

Beacon Huntress Default Settings

  • Raw Bro/Zeek logs are copied to /tmp/raw/data.
  • All connections using ports 80 and 443 are included.
  • Local connections, i.e., connections with 127.0.0.1 as the source or destination, are excluded.
  • Various high-usage top sites are excluded. See Default Filtered Hosts for the list of filtered sites.

Docker Setup

The quickest way to set up this software is via docker-compose.

Before starting, please ensure the following:

  • Docker is installed and running (check with docker --version in the terminal).
  • Docker-compose is installed (check with docker-compose --version or docker compose --version in the terminal).
  • You have Zeek connection logs available.
  • You have downloaded the Valkyrie Framework.

Good to go? Next, proceed with the following in the terminal:

  1. cd to the Valkyrie Framework directory
  2. Run docker-compose up -d or docker compose up -d depending on your Docker version. This will create the database, and may take some time to complete.
  3. Note that some Docker volumes were created.
  4. _mysql is your database, so that if the container stops, you do not lose previously saved data
  5. Visit http://127.0.0.1:8000 in your web browser to access the Beacon Huntress Web UI.
  6. Continue to the Tutorial section for examples on how to start using Beacon Huntress.

For troubleshooting, check docker logs -f beacon_huntress to access Web UI logging.

Note

Beacon Huntress Docker containers will fail if you attempt to use any of the following ports:

  • 3000 (Grafana)
  • 3306 (MySQL)
  • 8000 (Django)

Once you have the list of IP's from the dashboard you should conduct further investigation and analysis of the Potential Beacons using tools such as nslookup, PCAP, etc. to assess their veracity. Depending on network traffic and Beacon Huntress configuration, some connections identified as Potential Beacons may not be malicious. You can filter these sites out of the results. For more details see the User Interface documentation.

See Tutorial for running Beacon Huntress.
